Mission Viejo, CA – Holt Integrated Circuits announced today that Bloomy Controls, Inc. (Bloomy) has chosen its Multi-Terminal BC/MT/2RT MIL-STD-1553B solution, the HI-6131PQI, and PM-DB2791S low-profile isolation transformers, for use in the Bloomy BCI-1553 C Series Module. The module from Bloomy provides a standards-compliant MIL-STD-1553B avionic bus interface for the National Instruments (NI) CompactRIO platform. Typical applications addressed by Bloomy with its BCI-1553 module include systems integration lab data systems and hardware-in-the-loop validation of embedded controls.
Because the HI-6131 is capable of acting as any choice of terminal (BC, RT or MT) concurrently and efficiently, it is the ideal choice for use in the compact BCI-1553 module. The flexibility of the Holt interface solution plus the power of the NI CompactRIO platform provides engineers with a wide variety of MIL-STD-1553B solutions for aerospace industry use, ranging from testing avionics devices to embedding terminals in the rugged CompactRIO form factor.
The HI-6131 is a MIL-STD-1553B Multi-Terminal IC with on-chip dual transceivers, available in plastic 64-pin QFP or 9 x 9 mm QFN packages. The device integrates a Bus Controller, Monitor Terminal and two independent Remote Terminals, all capable of operating concurrently. Host communication is via a compact 4-wire Serial Peripheral Interface (SPI). Message information and data are stored in the on-chip 32K x 16-bit static RAM which has an optional error detection/correction capability. In addition, a second SPI port is available to read data from an external serial EEPROM, enabling optional auto-configuration of the internal RAM, registers and host interrupts.
Bloomy incorporates the functionality of the HI-6131 into its BCI-1553 C Series module and makes the basic RT, MT or BC functionality available to end users with ready-to-use LabVIEW drivers. An advanced mode driver provides access to the full functionality of the Holt interface solution, including using multiple modes simultaneously and accessing the configuration EEPROM. The advanced functionality mode also allows fault insertion, such as parity error and bit error injection. The module is supplied with access to all drivers, sample code and comprehensive documentation to allow users to rapidly develop custom applications.
“Holt is thrilled to be chosen by Bloomy to provide the principal component for the MIL-STD-1553 interface in their cRIO module,” said Sean Sleicher, Director of Business Development at Holt. “This multi-terminal solution provides the perfect mix of features for a compact, low power, efficient solution.”
“When we chose the Holt interface solution as the foundation of our cRIO module, we recognized that its flexibility provides an unprecedented level of MIL-STD-1553B functionality,” said Roy Walker, Aerospace Real-Time Test Business Manager at Bloomy. “As a result, our customers are able to implement high-speed, high-performance MIL-STD-1553B interfaces more efficiently and effectively using the power and simplicity of LabVIEW.”
To request information on Holt’s integrated circuits for ARINC 429, CAN, MIL-STD-1553 and other product lines, readers should contact Holt at (949)859-8800, by e-mail at [email protected], or visit the Holt website at www.holtic.com.To request information on Bloomy’s modules for ARINC-429, MIL-STD-1553 and other product lines supporting the NI platforms, as well as turnkey avionic test systems, readers should contact Bloomy at (860)298-9925, by e-mail at [email protected], or visit the Bloomy website at www.bloomy.com.
About Holt Integrated Circuits
Located in Mission Viejo, CA, Holt Integrated Circuits is a major supplier of ICs for avionics and military aircraft data bus and display applications. The company’s products are specified by more than 400 manufacturers worldwide and are employed in flight control, navigation, engine management, communications, safety equipment, and in-flight entertainment systems.
Holt’s range of ICs supporting the ARINC 429 standard is the widest in the industry, and its MIL-STD-1553 transceivers are recognized as the industry’s smallest, having the lowest power consumption. In addition, Holt MIL-STD-1553 integrated terminals offer the most compact, cost effective solution available, integrating protocol, transceiver and transformers in a single 16x16mm package. Other data bus products include ARINC 717, CAN (ARINC 825), RS-485/422 and analog switches. Select products are available to DSCC SMD specifications. Holt also offers product compliant to the European Union "RoHS Directive 002/95/EC".
Holt Integrated Circuits is ISO 9001:2008 registered and is a STACK certified supplier and recipient of the latest STACK International Gold Supplier Award.
